StarMiner 601 Firmware Flashing Guide
June 12, 2026 | Firmware Update
⚠️ IMPORTANT – Preparation & Key Notes:
- Use a USB data cable (charging-only cables will not work).
- Use the original power adapter that comes with the device.
- The device must complete the firmware upgrade within 2 minutes after power‑on. If an abnormality occurs during the upgrade, power off the device, let it cool down completely, and then retry (this applies when the fan stops running).
Step 1 – Open the Flashing Tool
Navigate to Star_Miner_601_Firmware_Flashing_Package\flash_download_tool_3.9.4 and locate the flash_download_tool executable.
Step 2 – Initial Tool Configuration
Double‑click to run the tool. Configure as shown below, then click OK.
Step 3 – Select Firmware & Set Parameters
- Click the "..." button to select the firmware (.bin) file you want to flash.
- Set the flashing address to
0.
Step 4 – Configure Flashing Options
Adjust the following settings as recommended:
-
SPI SPEED –
40MHz -
SPI MODE –
QIO -
BAUD –
115200(you can try a lower value if flashing fails)
Step 5 – Select COM Port & Start Flashing
After connecting the device correctly, a new COM port will appear in the dropdown list. Select that COM port, then click START.
Step 6 – Completion
When you see the success message (or the tool finishes without errors), the firmware has been flashed successfully. Press the reset button on the device or power cycle it to see the new firmware running.
❓ Frequently Asked Questions
5.1 – No COM port found?
5.2 – Flashing fails or stops midway?
5.3 – Device does not run after flashing?
5.4 – START button does not begin flashing?
5.5 – Can I flash firmware from other sources?
📌 Note: If any step is unclear or you encounter issues, contact our support team at support@ustarminer.com.
